Essentials Training
October 24-26, 2023
NexGenCAM leadership has over 80 years of combined experience in production shop and manufacturing. All support staff has a background in running CNC machines.
- PartMaker Essentials / basics course 3-days This class is designed to teach users how to create Swiss Style programming using the Autodesk Partmaker Swisscam interface. The student will learn how to setup toolpaths, tool libraries, cycles libraries and the use of the process table to order, edit and synchronize toolpaths between the main and sub spindles.
- Day 1 Course Objectives: Day 1 covers the Partmaker Swiss interface including job setup, importing of files, setting up tool libraries, cycle files and learning the use of the setup dialog page and introducing the process table. Turning strategies including facing, OD turning, drilling cycles and an introduction into simple milling ops.
- Day 2 Course Objectives: Day 2 covers machining strategies with an emphasis on 2D milling operations. Students will explore more of the face windows options, turning operations including boring and groove strategies will be explored. Milling operations include the use of polar strategies, indexing strategies, milling side
operations and hole making strategies. - Day 3 Course Objectives: Day 3 covers machining strategies with an emphasis on 2D milling, cylindrical milling and advanced milling strategies for pocketing and contouring. Synchronization of main and sub spindle, Post processing, Setup sheet generation.
Additional Information:
- Dates:
- Essentials 3-day Training: Octobe 24th-26th
- Time: 8:00AM- 4:00PM
- Location: 6584 Poplar Ave 2ndfl Memphis, TN 38138
- Investment:
- Essentials 3-day Training: $1600 per person
Food and Drinks provided.
PartMaker Training Registration Form
A Platinum Machine Tool Sales Associate will contact you to confirm your registration and next steps.
EXPERT LEVEL
SOLUTIONS
Best-in-Class Software
and Support
BEST IN THE
MARKET
2019 Top Autodesk
CAM partner
EASY TO USE
Intuitive software,
built for CNC
machines
FASTEST ROI
Increased machine
up-time & shorter
time-to-market
BROACHING
Create all types of broaching operations including rotary, indexed, and keyway broaching operations.
Create all types of broaching operations including rotary, indexed, and keyway broaching operations.
THREADWHIRLING
Increase threading productivity with a multi-insert whirling head.
Increase threading productivity with a multi-insert whirling head.
POLAR AND CYLINDRICAL MILLING
Create concentric milled features and overcome the limits of Y-axis travel by utilizing C-axis polar interpolation. Machine wrapped features around the OD of the part with cylindrical machining.
Create concentric milled features and overcome the limits of Y-axis travel by utilizing C-axis polar interpolation. Machine wrapped features around the OD of the part with cylindrical machining.
B-AXIS MILLING
Mill on an angle using a programmable B-axis or angled live holder with inclined plane machining
Mill on an angle using a programmable B-axis or angled live holder with inclined plane machining
